Surplus to our current needs, was pulled from a running 9/16″ Acme RA-6

Cleaned and checked out, runs super quiet

Winsmith speed reducer / gearbox & 1/3 HP Baldor motor

Wardcraft conveyor belt, believe they are the original manufacturer

Additional pictures available upon request

Unit is also listed on Ebay, but please purchase direct and not through Ebay

https://www.ebay.com/itm/186076435456





Spindle hole diameter: 26 mm

Control: Siemens Simatic OP 27

Bar Size Diameter:
-Round: 26mm
-Square: 19mm
-Hexagonal: 22mm
-Octagonal: 24mm

Normal/Special Feed of the Bar up to: 125mm / 290mm
-Normal (Total/Working Travel): 80mm / 64mm
-Special (Total/Working Travel): 115mm / 90mm

Travel of Cross Slides (Total Travel / Working Travel)
-Upper Slide: 32/23mm
-Central Upper Slide: 32/20mm
-Central Lower Slide: 40/22mm
-Lower Slide: 50/30mm

Number of Spindle Speeds: 49

Spindle Speeds
-Range One: 600 – 5,000 RPM

Driving Motor Power: 29 HP

Great running Eurotech 446 in excellent condition.  Machine has been well taken care of by our maintenance team.  Machine will come with some basic tool holders and collets.

Year: 2011

Serial# 10947

1) of 10.57.85.00 Cutoff tool holder cutoff shank .750”
(2) of MT 10.57.60.00 Radial Static Tool
(2) of Low Profile Radial Static Tool
(2) of Single axial stick holder
(1) of 42mm Sub Spindle Collet Chuck
(1) of 65mm Hainbuch Nova Quick Change Collet System
Fanuc 31i-Model A CNC Control, 8-axis
Spindle option for 2″ cap
Full Length Parts Conveyor w/90 degree exit conveyor
Dual Turrets
Coolant-thru-the-turret option
(1) Renishaw Tool Setting Probes
Y-Axis on Upper/Lower Turret
5-High flow coolant pumps
Combination Chip Conveyor/Coolant-chip tank

Approx Hours :
Power On: 53,102
Run Time: 27,232
Cut Time: 16,858

Specifications

Swing 20″
# Axis 8
Bar Capacity 2″
Chuck Size 8″
Distance Between Centers 37.5″
Power 20 hp
Max RPM 5,000 RPM
Tailstock No
Live Tooling Yes
Sub Spindle Yes
# of Turrets 2
Control CNC (FANUC)
Dimensions 173″ x 85″ x 89″
Weight 17,400 lbs

To the best of our knowledge all details listed below are deemed correct.
It is the buyer’s responsibility to confirmed prior to purchase.

General Specifications As Per Brochure (Please Verify Details):

Number of Axes: 8

Bar Capacity: 2″
Machining Diameter: 9.6″
Swing Over Diameter: 20″

Main Spindle
Spindle Speed: 5,000 RPM
Spindle Nose: 5″
Spindle Bore: 2.17″
Chuck Diameter: 8″
Motor Power: 20 HP
C-Axis Least Input Value: 0.001 Deg.

Sub Spindle
Spindle Speed: 5,000 RPM
Spindle Nose: 5″
Spindle Bore: 2.17″
Chuck Diameter: 6.5″
Motor Power: 15 HP
C-Axis Least Input Value: 0.001 Deg.
Clear Shift Travel: 4.72″

Upper Turret
Number of Stations: 12
Number of Static Tools: 96
Turret Indexing: 0.10
Number of Live Tools: 24
Live Tool Speeds: 4,000 – 60,000 RPM
Motor Power (30 Min Rating): 5 Geared

Lower Turret
Number of Stations: 12
Number of Static Tools: 96
Turret Indexing: 0.10
Number of Live Tools: 24
Live Tool Speeds: 4,000 – 60,000 RPM
Motor Power: 5 Geared

Cooling System Tank Capacity: 120 Gallons

Machine Dimensions: 173″ x 85″ x 89″
Machine Weight: 15,855

Power On Hours: 53,102
Run Hours: 27,232
Cutting Time: 16,858

Great running Eurotech 446 in excellent condition.  Machine is currently still under power.

Year: 2010

Serial #10731

Fanuc 31iT CNC Control
CoolBlaster Dual High Pressure Coolant System w/ Filter (1/turret)
Accu Chiller Coolant Refrigeration System w/ Filter
Combination Chip Conveyor/Coolant-chip tank
Main & Sub Spindle Collet Chucks
3-High flow coolant pumps
Equipped With:
Approx Tooling
(1) of Biglia T134-00059 Toolholder
(2) of MT 10.57.60.00 Radial Static Tool
(2) of Low Profile Radial Static Tool
(2) of MT 10.88.14.01 Sub Spindle Turning Toolholder
(1) of Algra T134-00061 Live Radial Toolholder
(2) of Static Endworking Holder
(1) of 42mm Sub Spindle Collet Chuck
(1) of 60mm Main Spindle Collet Chuck

Hexagon 4.5.4 SF CMM in excellent condition.  Unit was used to measure a couple of jobs and has been idle for about 95% of the time.  Has never been on the shop floor and always kept in a QC Lab.  Does come equipped with an assortment of probes as seen in the pictures.
